产品描述：1/4"-2" 4SP, 200T Force, ISO/CE/TUV
Feature description:
● Automatic Control with Foot pedal
● Up to 2" 4SP Hydraulic Hose
● Energy Saving and Safety Operation
Specification:
Main Specification | max DX68 |
Max Hydraulic Hose | 2" 4SP |
Crimping Range | 4-87mm |
Die Type | M32 |
Master Die Length | 80mm |
Max Opening | +25mm |
Motor | 3kW/4kW |
Crimping Force | 2000kN |
Die Sets | 10sets |
Control | Automatic |
Foot pedal | Included |
Die Rack | Optional |
Quick Change Tool | Optional |
Backstop Device | Optional |
Control by Pressure | Optional |
Noise Level | 65dBA |
Protection Class | IP56 |
L*W*H | 810*530*790mm |
Weight | 220kg |
Optional Standard Die Sets:
Die No. | 10 | 12 | 14 | 16 | 19 | 22 | 26 | 30 | 34 | 39 | 45 | 51 | 57 | 63 | 69 | 74 | 78 |
Length | 60 | 60 | 60 | 60 | 60 | 75 | 75 | 75 | 80 | 80 | 90 | 90 | 100 | 100 | 100 | 110 | 110 |
* Special Die sets or dedicated die sets for RYCO PARKER Manuli Eaton hose available upon request.
